ZMS CABLE PRODUCTS

ZMS as a professional electric cable manufacturer, specializes in producing all kinds of cable and cable accessories. In addition to overhead power lines, it also produces control cables, XLPE insulated cables, underground cables, concentric cables, armored cables, industrial cables, submarine cables, special cables, and so on. We produce and export cables in more than 100 countries around the world, with AAA guarantee of quality and service reputation.

Get A Free Quotation

ZMS MAIN CABLE TYPES

Subsea Cable applies to a solidly earthed system with a power frequency of 50-60Hz and rated voltage from 1kV to 500kV. Mainly used for high-power electric power transmission between mainland and island, island and island, or mainland and platform; control signal transmission of smart gird and communication signal transmission.

STANDARDS: IEC 60502, IEC 62067

OVERHEAD LINE

ABC Cable Aerial Bundle Cable: BS-7870, NFC 33-209, ANSI/ICEA S-76-474 Duplex Service Drop Cable
AAC– All Aluminium Conductor
AAAC – All Aluminium Alloy Conductor
ACSR-Aluminium Conductor Steel-reinforced, AACSR – Aluminium Alloy Conductor Steel-reinforced
ASTM B231, ASTM B399, BS 3242. BS 215, DIN 48201, IEC 61089

ZMS also produces a wide range of high-quality overhead line equipment for customers to choose from, in the hope that it will be easier to install cables.

– Copper/XLPE/PE(PVC) control cable
– Copper/XLPE/SWA/PE(PVC) control cable
– Copper/XLPE/SWA/LSZH control cable
– Copper/XLPE/Al-Foil/SWA/PE(PVC) Instrument cable
– Copper/XLPE/Al-Foil/SWA/LSZH Instrument cable

ZMS can fulfill all your control cable types if you have a cable order.

STANDARDS: IEC60502

Voltage level refers to the series of rated voltage levels of power systems and power equipment. There are several different criteria for dividing voltage levels. Low voltage refers to the voltage level of 1000V and below in the AC system used for power distribution, that is, 1000V is the standard in AC power, and high voltage usually refers to the voltage level that exceeds the low voltage.

ZMS produces concentric cables consisting of single or multi-core conductors with an insulating layer between the multi-core conductors, which effectively prevents electromagnetic interference between the two conductors. They are commonly used as energy supply cables. They are most commonly used in power distribution, panels, and street lighting.

STANDARDS: BS 7870-3-11, EN 60228、Flame Retardant according to IEC/EN 60332-1-2

PVC Insulated Wires: 450/750V-SINGLE CORE (CU / PVC), 600/1000V-SINGLE CORE (CU /PVC)
Technical Data Tables: Current Rating & Voltage Drop, Current Caring Capacity(Amps), Voltage Drop (mV/A/m), Rating factor for variation in ambient temperature, Correction Factor for groups of Cable
Flexible Cords: 450/750V-Single Core Flexible Cables (CU/PVC), 600/1000V-Single Core Flexible Cables (CU / PVC), 300/500V-Two Core Flexible Cords (CU / PVC / PVC)

Standards: BS 6004/BS 6231, BS6500/BS 6141 /BS 6004, BS 6004 / Client specification

The armored cable includes an armored thermocouple, optical fiber armored cable, armored RTD, armored heater, and armored lead, mainly used in the chemical industry, metallurgy, machinery manufacturing, power generation and scientific experiments, etc. temperature measurement, signal transmission, and special heating, the largest amount of armored thermocouple. ZMS also can provide armored cable connectors.

Standard: IEC60502, IEC60228

CABLE HOT SELLING

ZMS manufactures and wholesales a wide range of fiber optic cable products. The main products include ADSS / OPGW / OPPC power fiber optic cables, optoelectronic composite cables, flame retardant fiber optic cables for mining, underwater fiber optic cables, power fiber optic cable fixtures, and other products. If you need, ZMS can also produce fiber optic patch cords and other general small optical cables.

STANDARDS: IEC 60793, ITU-T G.650, ITU-T G.652, ITU-TG.655, IEEE Std 1138, IEC Std 1222

ZMS PVC insulated cable consists of PVC resin, stabilizers, plasticizers, fillers, lubricants, and so on. It has relatively high voltage and insulation resistance, good flame retardancy, oil resistance, corona resistance, chemical resistance, and water resistance.

Standards: BS 6004/BS 6231, BS6500/BS 6141 /BS 6004, BS 6004 / Client specification

Compared with overhead lines, underground direct buried cables have the advantages of a small footprint, reliable power transmission, and strong anti-interference ability. Underground cables that can be buried directly are control cables, compensation cables, shielded cables, high-temperature cables, computer cables, signal cables, and marine cables.

Standard: IEC 60502/BS 6622, IEC 60228, IEC 60332-1&IEC 60332-3, IEC 61034-2, IEC 60754-1, IEC 60986, IEC 60287

The rubber insulated flexible cables are mostly used for power connection of electric equipment, electric tools, and various moveable electric devices such as boilers, heating plates, hand lamps, transportable motors, lifts, and cranes.

STANDARDS: IEC60245

OTHER CABLE TYPES

The voltage level of high-voltage cables is 35kv-220kv.
– Rated Voltage from 30kV to 500kV
– Copper Conductor XLPE insulation corrugated aluminum(metallic) sheath outer sheath Copper Conductor – XLPE insulation copper wire and copper tape screen outer sheath
– Copper Conductor XLPE insulation lead alloy sheath outer sheath.

STANDARDS: IEC60840, IEC62067

ZMS Aluminum core cable specifications are classified by core as single core, double core, triple core, quadruple core, five core, and multi-core. The use can be divided into power, control, signal, and so on. The protective layer is divided into armored, and non-armored. zms cables accept customization.

STANDARDS: IEC60840, IEC62067

Coaxial cables are used as transmission cables for radio frequency signals. Common applications for coaxial cables include video and CATV distribution, RF and microwave transmission, and computer and instrument data connections.
A coaxial cable is made up of concentric electrical conductors and a layer of insulating material. This structure ensures that the signal is enclosed in the cable and prevents external interference with the signal.

Standard: MIL-C-17F, MIL-C-17G

SPECIAL CABLES

ZMS Cables also specializes in the production of special types of cables that are more demanding in the market, such as photovoltaic cables, airport lighting cables, self-regulating heating cables, and so on. We have rich experience and transaction cases in this area and can give the appropriate customized solutions according to the customer’s specifications. In addition, there are energy cables, fiber optic patch cords and so on.

ZMS CABLE CATALOG

ZMS CABLE PRODUCT SAMPLE PDF

ZMS provides our partners around the world with brochures of our cable products, including aerial cables, submarine cables, control cables and other types of special cables, and more.

If you don’t know how to choose the product you need or don’t find the cable type and size you need on this page, don’t worry. Contact us and send us your requirements, and we can help you choose the right cable. You can provide us with the following information: cable voltage, conductor material, insulation and sheath material, shield type, armor type, etc. or you can provide us with cable installation environment, application requirements, etc. We will serve you wholeheartedly. ZMS can provide custom electrical cable service according to customer’s order requirements. ZMS cable supplier has several quality certifications: ISO 9000, ISO 9001, ISO14000, ISO14001, ISO18000, CE, IEC, BS, NFC, ASTM, DIN, etc.

ABOUT ZMS CABLE

ZMS, established in 1990, is the earliest private enterprise in Henan (China) cable business. Our cables are manufactured by the most up-to-date technology, ensuring the highest quality, moreover, we continuously improve the management system, guaranteeing the stability of quality.

ZMS Cable have a wide product scope, includes: Overhead lines,Power cables up to 500kV, Flexible cables, Control cables, Rubber cables, Fiber Optical Cable,Submarine cables etc. With advanced manufacture technology, rich human resource and effective management system, we guarantee all products are manufactured strictly in accordance with GB, IEC, BS. NFC, ASTM,DIN standards,etc. Beyond quality control, ZMS have been trying its best to offer much higher standard of services rather than expected.

In the past decades, ZMS have built a wide sales network in global market, including Middle East, Africa,Southeast Asia, America, EU, over 90 countries. Our overseas projects evolved State grid electricity,city/railway electric transport, submarine cable, solar power plant, substation, etc.

ZMS Cable – Trans More Than Cables.Customers’ satisfaction is our primary aim. Apart from the qualified products and competitive prices, we also provide excellence back-up services and customized cable solutions to be your reliable supplier/partner.

Service of ZMS Company

Over Productions Service: ZMS has a wide range of cable and conductor products for you to choose from. We will provide caring services and professional project solutions for everyone who needs them.

Quality Certification Services: ZMS cable products are manufactured according to GB, IEC, BS, NFC, ASTM, DIN, and other international standards. Our technical team can customize cable products that meet your requirements according to your needs.

Profession Customer Service: ZMS provides free professional consulting services to provide you with one-stop project solution services and rapid product delivery solutions.

Delivery And Shipping Services: While we at ZMS provide high-quality cables, we also provide good delivery solutions. While ensuring the safe delivery of products, we provide the best packaging and transportation solutions, greatly reducing customers’ transportation costs.

Packaging of ZMS: ZMS cable packaging is provided in the form of wooden reels, corrugated boxes, and coils. The cable ends are sealed with BOPP self-adhesive tape and a non-hygroscopic sealing cap to protect the cable ends from moisture. We can print the required marks on the outside of the barrel with waterproof material according to customer requirements.
